In many industrial areas, fluorine rubber and silicone rubber are replacing a number of common elastomer to meet variety environmental requirements , to increase the product life and to improve production efficiency. Fluorine rubber and silicone rubber can provide higher performance, especially under high temperature and high corrosive environments in industrial equipment, such as the O-ring in gasoline mixed metering pump , high vacuum seals in the proton accelerator, the connectors of gas discharge pipe with heat and corrosion resistance. Silicone rubber sheet can also be equipped with solar component in the packaging laminating machine or block board wood shavings. Fluorine rubber product are widely used in following equipment:
|
| Oil pressure or lubrication machine |
|
| Acid washing Squeeze roller |
|
|
|
| Sealer of automatic packer |
|
|
|
toro bravo watches |
|
|
|
| Oil & Chemical Processing |
[TOP] |
|
|
|
|
In the chemical industry field, fluorine rubber sealing products can be sealed inorganic acid (such as 67% of the sulfuric acid under140 ℃, concentrated hydrochloric acid under 70 ℃, 30% of nitric acid under 90 ℃), organic solvents (such as hydrochloric ether, high aromatics gasoline) and other organic compounds (such as butadiene, styrene, acrylonitrile, phenol, fatty acids under 275 ℃ etc.). The fluorine rubber pipe is being widely applied to chemical liquids and gases delivery projects. Fluorine rubber hose when drilling in deep oil can withstand 149 ℃ and 420 atmospheres and harsh working conditions. Fluorine rubber product are widely used in following equipment:
|
|
|
|
| Printing and dyeing roller |
|
|
| cushion Sealer of needle valve |
|
|
| flow meter and pipe sealer |
|
|
|
|
|
|
| Wire & Cable Jacket |
[TOP] |
|
|
|
|
Wire and Cable jacket of fluorine rubber show good high temperature ,oil and special chemical fluid resistance. The insulation and flexibility properties are excellent as well. Such kind of products are widely used to produce the jackets of special wire and cables. are widely used in following equipment:
|
| Insulation oil plug of high speed train |
|
| Liquid sealed transformer |
|
|
| Oil or heat resistance cable |
|
|
|
|
|
|
|
|
|
|
|
|
|
In automotive engines, transmissions and other power systems or exhaust systems, the fluorine rubber seals can work for long term under 200 to 250℃, short term at 300 ℃. its life spans 5 to 10 years. The oil pipe made of fluorine rubber can effectively reduce fuel penetration, improve component performance. Fluorine rubber product are widely used in following equipment:trustytime
|
|
|
|
| Cable jacket of wiring harness around engine Oil |
|
|
| Fuel injection mechanism sealer |
|
|
| Sealer of Auto air conditioner compressor |
|
|
|
| Soft pipe of exhaust recycle air |
|
|
|
|
|
|
|
| Earth Water Resource |
[TOP] |
|
|
|
|
Chuangqi's micro-drop soaker hose has been exported to North American market, which is targeted to irrigate desert s to oasis. Chuangqi are devoting to use green energy and save Earth's water resources. |
|
|
|
|
|
|
|
|
Fluorine rubber shows incomparable advantage comparing with other kinds of rubber. So it has been used to make the sealer of military ordnance equipments, instruments. |
|
|
|
|
|
|
|
|
The basic requirement of the material used in aerospace should be security and reliability under extremely harsh conditions. In the height of more than 643km, the pressure will fall to 133X10-7Pa, no rubber can stand such high vacuum except fluorine rubber. FFKM seals can work for long term during aircraft climbs and falls in the atmosphere , when the temperature will change from -54 ℃to 316℃.Chuangqi has developed the O-ring of vacuum space simulation with Tieling Rubber Research Institute successfully, which weighing 1.27 kg and 43 meters circumference. Fluorine rubber is being the major rubber material of aircraft since it outstanding performance of vacuum resistance, excellent heat resistance, wear resistance and high reliability features. |
|
|
|
|
|
|
